- Pressure : 25kg / cm2g
- Seal : 16kg / cm2g
- Maximum Working Temperature : 220 °C
- Use : Water
| 1/2” | 3/4” | 1” | 1.1/4” | 1.1/2” | 2” | |
| DN | 15 | 20 | 25 | 32 | 40 | 50 |
| A | 52 | 57 | 64 | 75 | 84 | 95 |
| B | 28 | 35 | 40.50 | 55 | 58 | 71 |
| C | 42 | 49 | 60 | 77 | 73 | 87 |
| D | 104 | 104 | 121 | 153 | 153 | 153 |
| E | 14 | 19 | 22 | 30 | 32 | 42 |
| F | 14 | 14 | 15 | 17 | 18 | 20 |
| AF | 23.50 | 29.50 | 36.50 | 46.50 | 51.50 | 65 |
| No | Qty. | Parts Name | Description | Material |
| 1 | 1 | Body | Forged, Nickelplated | CW617N |
| 2 | 1 | Adaptor Nut | Forged, Nickelplated | CW617N |
| 3 | 1 | Ball | Polished, Chromeplated | CW617N |
| 4 | 2 | Seat Ring | Virgin Powder | PTFE |
| 5 | 1 | Steam | Brass | CW617N |
| 6 | 1 | Seal Ring | Virgin Powder | PTFE |
| 7 | 1 | Nut | Nickelplated | CW617N |
| 8 | 1 | Lock Nut | Nickelplated | CW617N |
| 9 | 1 | Lever Handle | Dacromet Coated | ALUMINIUM |
