- Pressure : 25kg / cm2g
- Maximum Working Temperature : 90 °C
- Use : Pump Discharges, HVAC System, Boilers
| 1/2" | 3/4” | 1” | 1.1/2" | 2" | |
| DN | 15 | 20 | 25 | 40 | 50 |
| A | 51 | 55 | 68 | 75 | 78 |
| B | 31 | 40 | 45 | 66 | 80 |
| C | 19 | 24 | 31 | 45 | 57 |
| AF | 25 | 31 | 39 | 55 | 67 |
| No. | Parts Name | Description | Material |
| 1 | Body | Forged Brass | CW617N |
| 2 | Nut | Forged Brass | CW617N |
| 3 | Washer | Rubber | NBR |
| 4 | Pin | Brass | CW617N |
| 5 | Spring | S.S. | S.S 304 |
