- Pressure : 25kg / cm2g
- Maximum Working Temperature : 90°c
- Use : Water Line, Pump Discharges, and Boilers
| 1/2” | 3/4” | 1” | 1.1/4” | 1.1/2” | 2” | |
| DN | 15 | 20 | 25 | 32 | 40 | 50 |
| A | 46 | 50 | 58 | 67 | 75 | 85 |
| B | 12 | 16 | 22 | 28 | 32 | 42 |
| C | 12 | 11 | 13 | 15 | 16 | 16 |
| D | 30 | 31 | 37 | 46 | 53 | 60 |
| AF | 25 | 30 | 37 | 46 | 53 | 67 |
| No. | Parts Name | Description | Material |
| 1 | Body | Forged Brass | CW617N |
| 2 | Cap | Forged Brass | CW617N |
| 3 | Dish | Brass | CW617N |
| 4 | GAS Ket | Rubber | NBR |
